Product Description
Epoxy AntiStatic Flooring ESD Electrostatic Dissipative Epoxy Flooring Featuring Two Component Formulation For Static Control
Epoxy Anti-static Floor Coating
Product Introduction:
Epoxy Anti-static Floor Coating is a two-component floor coating that can effectively and quickly dissipate static charges, maintaining long-lasting anti-static effectiveness. Its surface resistivity reaches 10⁶Ω-10⁹Ω, and the ground resistance dissipation meets international standards.
Application Scope:
Epoxy Anti-static Floor Coating is especially suitable for floors of aerospace, computer rooms, electronic enterprises, industrial enterprises, dam control centers and various flammable and explosive workshops.
Performance Characteristics:
1.Compression and impact resistance, high strength and good toughness;
2.Resistivity of 10⁵-10⁹Ω, long-lasting anti-static performance;
3.Flat paint film with texture;
4.Easy to clean and stain-resistant.
Construction Process:
1.Base Treatment: Grind and clean, the base surface must be dry, flat and free of hollowing;
2.Primer Application: Seal and apply anti-static primer;
3.Epoxy Middle Coat: Scrape and apply epoxy mortar;
4.Lay Conductive Copper Foil;
5.Scrape and apply anti-static epoxy middle coat sand putty;
6.Grind and vacuum the middle coat;
7.Apply anti-static epoxy topcoat (flat coat or self-leveling).
Technical Indicators:
Parameter | Value Range/Value | Unit |
|---|---|---|
Resistance | 1.0×10⁶Ω ~ 1.0×10¹¹Ω | Ω |
Adhesion | Grade 1 | (Cross-cut Method) |
Wear Resistance | ≤ 0.02g | g (500g/1000 rotations) |
Compressive Strength | ≥ 80MPa | MPa |
Pencil Hardness | ≥ 2H | - |
Technical specifications
| Property | Value |
|---|---|
| Pencil Hardness | ≥ 2H |
| Wear Resistance | ≤ 0.02g · g (500g/1000 rotations) |
| Resistance | 1.0×10⁶Ω ~ 1.0×10¹¹Ω · Ω |
| Adhesion | Grade 1 · (Cross-cut Method) |
| Compressive Strength | ≥ 80MPa · MPa |
